Sperry Instruments DSA600TRMSR Clamp Meter, 28, Backlit LCD Digital Display, Functions: 12, Yellow

Sperry Instruments

Sperry Instruments DSA600TRMSR Clamp Meter, 28, Backlit LCD Digital Display, Functions: 12, Yellow

Sperry Instruments DSA600TRMSR Clamp Meter, 28, Backlit LCD Digital Display, Functions: 12, Yellow
  • Color: Yellow
  • Dimensions: 8-1/4 x 2-1/4 x 1-1/4 in
  • Display Type: Backlit LCD Digital
  • Measuring Functions: 12
  • Measuring Range: 28
  • Model #: DSA600TRMS
  • UPC #: 035632200733
  • SKU: 221061

Availability

Product Details

The Sperry Instruments DSA600TRMS true RMS clamp meter has more features and functions without the extra cost! This clamp meter offers a large range of superior functions like advanced temperature measurements and peak hold. The meter gives true RMS readings and measures current without having to contact live conductors. This unit features a data hold switch to maintain the reading on the 5999 count backlit screen and auto power-off functionality to extend battery life. The built-in low battery indicator will ensure you won't get incorrect readings due to low batteries. Audible beeper offers easy continuity check (buzzer sounds at 100 Ohm or less). We consider safety first, this instrument has been designed and tested according to cETLus standards and is CAT 3 600 V rated. This compact, lightweight, yet durable unit has a crush rating of 250 lb and a 10 ft drop rating - the best in the industry. Measuring ranges: 6 to 600 A AC, Current 60 mV to 600 V DC, Voltage 6 to 600 VAC, Voltage 99.99 KHz, Frequency 0.1 to 99.9, Duty Cycle 0 to 1000 deg C/32 to 1832 deg, F Temperature 600 to 600, MOhm Resistance 6 nF to 600uF Capacitance.

Item Specifications

ColorYellow
Dimensions8-1/4 x 2-1/4 x 1-1/4 in
Display TypeBacklit LCD Digital
Measuring Functions12
Measuring Range28
Power SourceBattery
Power Supply600 VAC/VDC
Resistance100 Ohm
