Romex 28828226 Building Wire, 12 AWG Wire, 2 -Conductor, 15 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

Romex

Romex 28828226 Building Wire, 12 AWG Wire, 2 -Conductor, 15 ft L, Copper Conductor, PVC Insulation, Nylon Sheath

Romex 28828226 Building Wire, 12 AWG Wire, 2 -Conductor, 15 ft L, Copper Conductor, PVC Insulation, Nylon Sheath
  • Conductor Insulation: PVC
  • Conductor Material: Copper
  • Current Rating: 20 A
  • Length: 15 ft
  • Number of Conductors: 2
  • Model #: 28828226
  • UPC #: 032886849435
  • SKU: 169758

Availability

Product Details

Southwire Romex Brand SIMpull NM-B (nonmetallic-sheathed) cable may be used for both exposed and concealed work in normally dry locations at temperatures not to exceed 90 deg C (with ampacity limited to that for 60 deg C conductors) as specified in the National Electrical Code. NM-B cable is primarily used in residential wiring as branch circuits for outlets, switches and other loads. NM-B cable may be run in air voids of masonry block or tile walls where such walls are not wet or damp locations. Voltage rating for NM-B cable is 600 V.

Item Specifications

Conductor InsulationPVC
Conductor MaterialCopper
Current Rating20 A
Length15 ft
Number of Conductors2
Operating Temperature90 deg C
Sheath ColorYellow
Sheath Diameter418 x 179 mil
Sheath MaterialNylon
Stranded/SolidSolid
Strands per Conductor1
TypeNM-B
Voltage Rating600 V
Wire Size12 AWG
